LaserPecker LP5 - The Smart 20W Fiber + Diode Laser Engraver
The Smart 20W
Dual Laser Engraver
Industry's smallest 2-in-1 laser engraver with 20W fiber and 20W diode laser sources,
versatile for engraving on almost all materials.
- The most capable, lightest weight, and most compact engraver in its class. Versatile and reliable on a wide range of materials, for multiple application scenarios.
- Engrave at up to 10,000mm/s, rapid engraving task completion, batch processing with variable text and smart filling.
- Deep engraving for high-contrast markings, vivid 3D grayscale embossing, ultra-precise metal cutting.
- Safely engrave and deliver instant services indoors, for retail stores, maker spaces and creative studios.
20W Fiber Laser
Stainless steel, aluminum, brass, silver, plastic, platinum, titanium, gold, and so on.
20W Diode Laser
Wood, acrylic, leather, glass, rock, paper, rubber, food, and so on.
Deep Engraving
Achieve greater depth in a single path with clean, well-defined edges, and exceptional details
3D Grayscale Embossing
Experience LaserPecker's software expertise and precision control for captivating grayscale engravings on wood, rocks, and metals.
Rediscover the joy of color engraving
Rather than limiting oneself to monochrome designs, the journey of experimenting with color engraving can inspire your craftsmanship.
Powerhouse in Portability
The LP5 is the most capable, lightest weight, and most compact engraver in its class, and its ease of portability makes it an ideal companion for versatile and on-the-go customization.
Handheld Engraving
With LP5, the possibilities for your projects are no longer limited by location or access to a stationary setup. Whether working on-site, in your workshop, or even outdoors, this compact and portable engraver allows you to create in the places that inspire you most.
Speed for Unmatched Efficiency
The LP5 is a speed beast, capable of engraving at up to 10,000mm/s, providing precise and rapid results akin to industrial-grade machines.
Specifications
| Type | Details |
|---|---|
| Dimension: | Laser Unit: 255 x 98 x 183mm Electric Stand: 198 x 286 x 323mm Conical Protective Cover: 167 x 231 x 160mm |
| Net Weight: | Laser Unit: 3.36 kg Electric Stand: 2.28 kg Conical Protective Cover: 0.38 kg Total Weight: 6.02 kg |
| Laser Power & Laser Source: | 20W 450nm Blue Diode Laser 20W 1064nm Fiber Laser |
| Working Area: | 120 x 160mm(Ellipse) 100 x 100mm(Square) 160 x 300mm(With the Slide Extension) |
| Laser Spot Size: | 0.08 x 0.1 mm(20W Diode Laser) 0.06 x 0.06 mm(20W Fiber Laser) |
| Max. Working Speed: | 10000mm/s |
| Engraving Precision: | 0.0027mm |
| Preview Mode: | Rectangle Preview/Outline Preview/Center Point Preview |
| Supported File Formats: | PC Software: G-code/JPG/PNG/BMP/SVG/DXF etc. Mobile App: G-code/JPG/PNG/SVG |
| Connectivity： | USB, Wi-Fi |
| Supported OS: | Support iOS 9.0+, Android 7.0+, macOS 10+, Windows 10+ Compatible with LightBurn |
| Safety Certification: | CE/ROHS/FCC/FDA/NCC/KC/UKCA/TELEC/SRRC |
