Creality Halot-Mage S 14K Resin 3D Printer with Print Speed up to 150mm per hour
Excludes GST
Print Miniatures and Jewellery Where Detail Does the Talking
Most resin printers force a trade-off where a finer pixel pitch means a smaller build plate, and a larger build plate means sacrificing detail. The Halot-Mage S resolves this by pairing a 14K panel running at 13,320 × 5,120 pixels across a 10.1" screen with an XY resolution of 16.8 × 24.8 microns. This means fine surface detail, sharp edges, and delicate features are preserved across the full 223 × 126 × 230mm build area and not just the centre of a smaller plate. In practical terms, you can print a full warband or a complete jewellery range in a single run without compromising the quality of any individual piece.
Consistent output depends on even light delivery, which is why Creality's Integral Light Source 3.0 drives the panel at greater than 90% uniformity across the entire surface. Uneven light is one of the most common causes of dimensional inaccuracy and surface inconsistency in resin printing, and this largely eliminates that variable. The high-speed Pictor release film reduces the peel force between the cured layer and the FEP surface, which is what allows print speeds of up to 150mm per hour without introducing layer separation or adhesion failures.
The laser-etched build plate works on the same principle, where mechanical surface texture creates a reliable bond at the first layer and that is where most print failures originate. Together, these systems mean the printer is engineered to remove the most common points of failure, so the output reflects the design rather than the hardware's limitations. The result is a machine where the hardware supports the work rather than becoming a reason to lower expectations.
Workflow Advantages
- 14K resolution across a full-size build plate — Design with confidence knowing the printer will hold fine filigree, facial detail, and sharp edges without having to simplify your work to suit the hardware.
- 223 × 126 × 230mm build volume — Print a full warband, a jewellery range, or a set of matched components in a single run, spending less time managing batches and more time on the work itself.
- Print speeds up to 150mm/h — Faster turnaround without sacrificing output quality means you can iterate, test, and deliver at a pace that suits a professional or semi-professional timeline.
- Integral Light Source 3.0 with >90% uniformity — Cure consistency across the entire build plate removes the uncertainty of printing multiple pieces simultaneously and expecting them all to meet the same standard.
- Laser-etched build plate — Reliable first-layer adhesion means fewer failed runs and less wasted resin, so you can focus on output rather than troubleshooting the same problem repeatedly.
- Built-in air purifier — Working with resin in a shared or enclosed space becomes more manageable, so the printing environment doesn't become a reason to limit how often or how long you print.
- Ethernet, Wi-Fi, and USB connectivity — Sending files directly from your workstation without handling USB drives repeatedly makes the printer feel like a natural part of a structured workspace rather than an isolated piece of equipment.
- CHITUBOX Pro VIP included (3 months) — Access to professional-grade slicing from day one means you're not held back by software limitations while you're still learning what the hardware is capable of.
- Creality Cloud printing support — Monitoring and managing print jobs remotely means you're not tied to the machine, which adds a level of flexibility that matters when you're running longer or overnight prints.
Why Kyro Machines Recommends Creality
Creality is one of the most established names in desktop fabrication, with products sold across more than 100 countries and a broad installed base spanning hobbyists, independent studios, and small-scale manufacturers. Their resin printer range has built a solid reputation over several product generations — the Halot series in particular has been well received by miniature painters, jewellery designers, and small production operations who need dependable, high-resolution output.
The Halot-Mage S sits toward the upper end of Creality's consumer resin range, reflecting a clear step up in panel resolution and build volume from their entry-level offerings. It is a machine aimed at buyers who have outgrown starter-level hardware and need a printer that can keep pace with more demanding work.
At Kyro Machines, we carefully select machines based on capability, reliability and suitability for real-world applications. Every machine in our range is backed by Australian-based support and guidance to help customers choose, implement and operate the right equipment for their workflow.
Key Features
- 14K Mono LCD (13,320 × 5,120) — 10.1" panel with 16.8 × 24.8μm XY resolution across the full build area
- Build volume: 223 × 126 × 230mm — Supports large single prints or high-density batch runs in one session
- Print speed up to 150mm/h — Enabled by high-speed Pictor release film with standard FEP also compatible
- Integral Light Source 3.0 — Greater than 90% light uniformity across the full build plate at 3,500μW/cm²
- Laser-etched build plate — Mechanical surface texture for consistent first-layer adhesion
- Built-in air purifier — Integrated into the unit; no separate enclosure required
- Three connectivity options — USB drive, RJ45 Ethernet, and Wi-Fi supported
- Slicing software compatibility — Works with HALOT BOX, CHITUBOX, and Tango; includes three months CHITUBOX Pro VIP
Technical Specifications
View Full Specifications
General
- Printing Technology LCD MSLA
- Build Volume 223 × 126 × 230mm (6,462cm³)
- Product Dimensions 333 × 270 × 608mm
- Net Weight 13.13kg
- Gross Weight 16.35kg
Printing
- Print Speed ≤150mm/h
- Layer Height 0.05–0.2mm
- LCD Screen 10.1" Mono LCD
- LCD Resolution 14K (13,320 × 5,120)
- XY Resolution 16.8 × 24.8μm
- Light Source Integral Light Source 3.0
- Light Uniformity >90%
- Light Intensity 3,500 ±10% μW/cm²
Display
- Touchscreen 4.3" colour display
Hardware
- Build Plate Laser-etched
- Release Film High-speed Pictor Film (standard); Regular FEP Film (compatible)
- Air Purifier Built-in
- Smart Resin Pump Optional accessory
- Rated Power 100W
- Noise Level 49dB (measured at 1m)
Connectivity
- USB Drive ✓
- RJ45 Ethernet ✓
- Wi-Fi ✓
Software & compatibility
- Slicing Software HALOT BOX, CHITUBOX, Tango
- Compatible OS Windows, macOS
- File Formats STL, OBJ
- Cloud Printing Creality Cloud (app-based)
- Included CHITUBOX Pro VIP — 3-month licence
Materials
- Compatible Resin 405nm photopolymer resins
Packaging
- Package Dimensions 421 × 356 × 672mm
- Packaged Weight 17.45kg
Warranty and Returns
This product is backed by the manufacturer’s warranty. Kyro Machines provides further support and guidance to help troubleshoot any issues and assist with the warranty process where required.
Due to the nature of specialised equipment, returns are handled in accordance with our Returns & Warranty Policy. If you’re unsure whether this machine is the right fit, we recommend contacting us before purchasing so we can help you make an informed decision.
If this fits your workflow and gives you the capability to produce the results you’re aiming for, add it to your cart to get started.
If you need help choosing the right machine for your workflow or use case, contact us and we’ll help you find the right solution.
